Suitable for heavy duty applications. Available in single/variable speeds as per requirements.
Power winch Machines
SALIENT FEATURES:
Design: Power Driven Winch Machines are designed as per IS-9507-1979 and are suitable for heavy Duty applications.
Base Frame: Fabricated with I.S.M.C. & C Sections/Plates property ribbed, floored with checkered plate platform for working area, lifting lugs, Anchoring Holes for foundation, provided.
Reducer: 1st stage reduction with self made Helical Reduction Gear box or of reputed make & other reduction with open Spur Gears & pinions.
Rope Drum: Steel fabricated Drum duly machined, with flanges at both ends.
Winding Capacity: 50-600 or more as per customer requirement.
Motor: High Starting Torque, Class 'B' Insulation, 150 Starts/ Hr415V, 50Hz, 3 Phase, A.C. Induction, squirrel Cage/Slipring motors conforming to IS-325 of reputed make .
Control & Control Panel: The winch is operated by Push Button Station/Controller at 110V. fixed on machine. The control Equipments like Triple Pole Reversing Contractors, H.R.C. Fuses, pilot lamp etc of reputed make.
Brake: Electromagnetic/Elector Hydraulic thruster, Double Shoe Type Brake and/or Hand Operated brake provided as per requirement.
